MTS552T2 SATA III M.2 SSD 256GB TS256GMTS552T2 Features: Firmware Dynamic thermal throttling Built-in LDPC ECC (Error Correction Code) functionality Advanced Global Wear-Leveling and Block management for reliability Advanced Garbage Collection Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices TRIM command for better performance NCQ command for better performance Full drive encryption with Advanced Encryption Standard (AES) (optional) Power-saving DevSleep (Device Sleep) mode Hardware Compliant with RoHS 2.0 standards Space-saving M.2 form factor (42mm) – ideal for mobile computing devices DDR3 DRAM Cache embedded Endurance: 3K P/E cycles (Program/Erase cycles) guaranteed Key components fortified by default with Corner Bond technology 30µ" PCB gold finger Extended Temp. (-20°C ~ 75°C) and Wide Temp. (-40°C ~ 85°C) options available Supports Transcend Scope Pro software Specifications: Appearance Dimensions 42.0 mm x 22.0 mm x 3.58 mm (1.65" x 0.87" x 0.14") Weight 5 g (0.18 oz) Form Factor M.2 M.2 Type 2242-D2-B-M (Double-sided) Interface Bus Interface SATA III 6Gb/s Storage Flash Type 3D NAND flash Capacity 256 GB Operating Environment Operating Voltage 3.3V±5% Operating Temperature -20°C (-4°F) ~ 75°C (167°F) Storage Temperature -55°C (-67°F) ~ 85°C (185°F) Humidity 5% ~ 95% Shock 1500 G, 0.5 ms, 3 axis Vibration (Operating) 20 G (peak-to-peak), 7 Hz ~ 2,000 Hz (frequency) Power Power Consumption (Operation) 1.7 watt(s) Power Consumption (Sleep) 0.3 watt(s) Performance Sequential Read/Write (CrystalDiskMark) Read: up to 560 MB/s, Write: up to 510 MB/s 4K Random Read/Write (IOmeter) Read: up to 85,000 IOPS, Write: up to 85,000 IOPS Mean Time Between Failures (MTBF) 3,000,000 hour(s) Terabytes Written (TBW) up to 880 TBW Drive Writes Per Day (DWPD) 1.61 (3 yrs) Warranty Certificate CE/FCC/BSMI Warranty Three-year Limited Warranty
